NEMA Motor Specification
| HP | Frame Size | E | F | H | BA | C | D | P | U | AH | AJ | AK | BF (QTY) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1 | 143 TC | 2.75 | 2.00 | 0.34 | 2.25 | 12.25 | 3.50 | 7.72 | 0.88 | 2.13 | 5.87 | 4.50 | 3/8-16 (4) |
2 | 145 TC | 2.75 | 2.50 | 0.34 | 2.25 | 13.25 | 3.50 | 7.72 | 0.88 | 2.13 | 5.87 | 4.50 | 3/8-16 (4) |
3 | 182 TC | 3.75 | 2.25 | 0.41 | 2.75 | 15.00 | 4.50 | 8.91 | 1.13 | 2.62 | 7.25 | 8.50 | 1/2-13 (4) |
5 | 184 TC | 3.75 | 2.75 | 0.41 | 2.75 | 15.63 | 4.50 | 8.91 | 1.13 | 2.62 | 7.25 | 8.50 | 1/2-13 (4) |
7.5 | 213 TC | 4.25 | 2.75 | 0.41 | 3.50 | 18.00 | 5.25 | 11.19 | 1.38 | 3.12 | 7.25 | 8.50 | 1/2-13 (4) |
10 | 215 TC | 4.25 | 3.50 | 0.41 | 3.50 | 19.50 | 5.25 | 11.19 | 1.38 | 3.12 | 7.25 | 8.50 | 1/2-13 (4) |
15 | 254 TC | 5.00 | 4.13 | 0.53 | 4.25 | 24.00 | 6.25 | 12.75 | 1.63 | 3.75 | 7.25 | 8.50 | 1/2-13 (4) |
20 | 256 TC | 5.00 | 5.00 | 0.53 | 4.25 | 25.60 | 6.25 | 12.75 | 1.63 | 3.75 | 7.25 | 8.50 | 1/2-13 (4) |
25 | 284 TC | 5.50 | 4.75 | 0.53 | 4.75 | 25.60 | 7.00 | 14.50 | 1.88 | 4.37 | 9.00 | 10.50 | 1/2-13 (4) |
30 | 286 TC | 5.50 | 5.50 | 0.53 | 4.75 | 27.09 | 7.00 | 14.50 | 1.88 | 4.37 | 9.00 | 10.50 | 1/2-13 (4) |
40 | 324 TC | 6.25 | 5.25 | 0.66 | 5.25 | 30.87 | 8.00 | 15.50 | 2.13 | 5.00 | 11.00 | 12.50 | 5/8-11 (4) |
50 | 326 TC | 6.25 | 6.00 | 0.66 | 5.25 | 30.86 | 8.00 | 15.50 | 2.13 | 5.00 | 11.00 | 12.50 | 5/8-11 (4) |
60 | 364 TC | 7.00 | 5.63 | 0.66 | 5.87 | 35.00 | 9.00 | 17.50 | 2.38 | 5.62 | 11.00 | 12.50 | 5/8-11 (8) |
75 | 365 TC | 7.00 | 6.13 | 0.66 | 5.87 | 36.00 | 9.00 | 17.50 | 2.38 | 5.62 | 11.00 | 12.50 | 5/8-11 (8) |
100 | 405 TC | 8.00 | 6.88 | 0.81 | 6.63 | 38.00 | 10.00 | 19.13 | 2.88 | 7.00 | 11.00 | 12.50 | 5/8-11 (8) |
125 | 444 TC | 9.00 | 7.25 | 0.81 | 7.50 | 43.00 | 11.00 | 22.06 | 3.38 | 8.25 | 14.00 | 16.00 | 5/8-11 (8) |
150 | 445 TC | 9.00 | 8.25 | 0.81 | 7.50 | 46.00 | 11.00 | 22.06 | 3.38 | 8.25 | 14.00 | 16.00 | 5/8-11 (8) |
